Honeywell 51196655100 Communication Interface Module

Technical Specifications

Model:51196655100

Brand:Honeywell

Product type:FSC safety communication interface module

System series:FSC Fail Safe Controller SIS

Bus type:Parallel backplane system bus

Compatible modules:FSC main controller, I/O boards, system backplane, redundant power supply

Redundancy:Supports DMR dual modular redundant / QMR quadruple modular redundant configuration

Power bus:5V DC,24V DC power supply

Operating temperature:0~+60℃

Relative humidity:5~95% non-condensing

Weight:4.09kg

Certification:CE,TÜV,SIL3

System compatibility

This interface card belongs to Honeywell FSC safety instrumented system and is mounted inside FSC rack cabinet. It serves as dedicated communication gateway connecting FSC safety controller and Experion PKS DCS. It transfers real-time process parameters, safety alarm events and equipment running status. Widely deployed in oil & gas, petrochemical and chemical facilities for ESD emergency shutdown and fire & gas safety protection.

Function

51196655100 undertakes bidirectional data interaction for FSC safety rack. It fetches safety logic operation outcomes and channel diagnostic information from main controller and uploads data to HMI workstation. Meanwhile, it receives query and configuration commands issued by upper monitoring platform and forwards instructions to FSC controller. It continuously checks communication link integrity and runs real-time link diagnosis.

Installation

Insert the module vertically into designated communication slot on FSC rack backplane. Complete backplane power wiring, set communication address and protocol parameters through Honeywell FSC engineering software.

Interface

‑Gold finger connector for backplane bus interconnection

‑External communication port for host system connection

‑Internal high-speed signal traces

‑LED indicators for operating status and communication fault warning

Circuit feature

Conformal coated multi-layer PCB design, equipped with isolated communication circuit to suppress electromagnetic interference. Embedded continuous link self-test mechanism, capable of rapidly identifying communication disconnection, fully meeting SIL3 functional safety requirements.

Feature

51196655100 is a spare communication board of Honeywell FSC SIS product line. Common defects include interface circuit burnout, gold finger corrosion and communication timeout failure. Verify rack slot definition and firmware version before replacement.

Diagnostic

Once communication interruption, signal jitter or hardware abnormality is detected, the module will trigger safety alarm and transmit detailed fault diagnostic logs to safety workstation.

Built‑in function

Bidirectional cross-platform data transmission and communication link health monitoring for FSC safety rack, used as SIS communication interface spare replacement.

Product Brief

51196655100 is Honeywell FSC SIL3 communication interface module,supporting DMR/QMR redundant setup. Confirm rack compatibility before purchase. ESD anti-static protection must be followed during handling and installation.
