HEIDENHAIN 359002-05 Encoder Cable Assembly

Technical Specifications

Model： 359002-05

Brand： HEIDENHAIN

Product Type: Shielded encoder signal cable assembly for linear and rotary encoders

Module Feature:

Function: HEIDENHAIN 359002-05 ready-made shielded encoder feedback cable. Transmits position and signal data between HEIDENHAIN encoders and CNC controller. Copper braid shield suppresses electromagnetic interference, ensures stable signal transmission for closed-loop axis control on heavy horizontal boring mills and large machining centers.

Cable type: Multi-core shielded encoder signal cable Matched Device: HEIDENHAIN linear scales, rotary encoders Onboard components: Tinned copper conductors, PE insulation, overall copper braid shield, molded connectors at both ends, strain relief structure

LED indicators: Not applicable (Cable assembly)

Hardware self-diagnosis: Continuity test, insulation resistance test, shield continuity inspection

Programming software: No programming required

Electrical Parameters

Voltage rating: 300V Conductor specification: Multi-core signal conductors

Mechanical & Structure:

Installation: Fixed routing inside machine cabinet and machine body Outer jacket: Oil resistant, flame retardant PUR jacket Bending radius: ≥10 × cable outer diameter

Protection class: IP64 (connector side)

Environmental:

Operating temperature: -20℃ ~ +80℃

Ambient humidity: 5~85% non-condensing

Certification: CE

Status: HEIDENHAIN standard encoder cable assembly

System compatibility

Compatibility description: 359002-05 belongs to HEIDENHAIN encoder accessory family. Compatible with HEIDENHAIN LS / LC series linear encoders and many rotary encoders. Suitable for Fives Giddings & Lewis PIC900 CNC heavy boring mills.

Function

Function description: 359002-05 is pre-assembled shielded encoder signal cable manufactured by HEIDENHAIN. It connects linear or rotary encoder to CNC control unit, carrying incremental or absolute position feedback signals. The full copper braid shield isolates signal from PWM servo power noise. PUR outer jacket resists coolant, oil mist and cutting chips in workshop environment. It is encoder feedback wiring spare for heavy CNC boring mills.

Installation

Installation steps: Follow lockout/tagout safety procedure before installation. Cut off encoder and CNC controller power. Disconnect old cable connectors at encoder and controller end. Route 359002-05 cable separately from servo power cables. Secure cable clamps and connectors. Check insulation resistance and shield grounding. Restore power, test encoder signal reading and monitor axis position stability.

Interface

Interface list: Encoder side connector, CNC controller signal connector for HEIDENHAIN 359002-05.

Diagnostic

Troubleshooting: No encoder signal: Check cable continuity, connector pin damage or wire breakage. Intermittent position fault: Poor shield grounding, connector corrosion or cable insulation aging. Signal amplitude drop: Excessive bending damage to internal wires or shield fracture.

Product Brief

Brief description: 359002-05 is HEIDENHAIN shielded encoder signal cable assembly,for transmitting position feedback signal between HEIDENHAIN encoders and CNC controller on heavy CNC boring mills,encoder wiring spare.
