HEIDENHAIN 1FK7042-5AF71-1EH2 Incremental Rotary Encoder

Technical Specifications

Model：1FK7042-5AF71-1EH2 Brand：HEIDENHAIN Product Type: Compact permanent magnet synchronous servo motor for CNC spindle and servo feed axis

Module Feature

Function: HEIDENHAIN 1FK7042-5AF71-1EH2 is a compact synchronous servo motor. It adopts natural surface cooling design, rated power 0.82kW, static torque 3Nm. Equipped with Drive-CLiQ multi-turn absolute encoder. Smooth shaft without keyway and no holding brake. The power and signal connectors can be rotated 270 degrees for flexible wiring. High overload capacity and compact housing save installation space. Widely used on heavy horizontal boring mills, machining centers and spindle closed-loop control systems.

Measuring principle: Permanent magnet synchronous rotation Shaft specification: Smooth shaft without keyway Rated power: 0.82kW Encoder Interface: Drive-CLiQ absolute multi-turn encoder Onboard components: Stator, rotor, Drive-CLiQ encoder, metal housing, rotatable power & signal connector

LED indicators: POWER, COM, FAULT diagnostic lights

Hardware self-diagnosis

Winding resistance test, insulation resistance detection, encoder signal amplitude monitoring, bearing temperature and noise inspection

Programming software

TIA Portal, STARTER software for motor parameter configuration and fault log reading

Electrical Parameters

Supply voltage: 60VDC ~600VDC Power consumption: Max 0.82kW

Mechanical & Structure

Mounting: IMB5 flange direct mounting Protection class: IP65 (housing)

Environmental

Operating temperature: -20℃ ~ +40℃ Ambient humidity: 5~85% non-condensing Certification: CE Status: HEIDENHAIN heavy-duty compact feed servo motor

System compatibility

Compatibility description: 1FK7 series servo motor matches HEIDENHAIN drive system. Suitable for Fives Giddings & Lewis PIC900 CNC heavy boring mill feed axis.

Function

Function description: 1FK7042-5AF71-1EH2 is permanent magnet synchronous servo motor manufactured by HEIDENHAIN. Natural cooling structure reduces fan maintenance work. Built-in Drive-CLiQ absolute encoder can directly read absolute position after power on without axis homing. Compact structure and strong overload capability satisfy high dynamic positioning requirements for machine tool feed axis. It is high precision drive spare for heavy CNC boring mills.

Installation

Installation steps: Follow lockout/tagout safety procedure before installation. Cut off motor power. Mount servo motor through IMB5 flange, connect shaft with mechanical structure. Connect power cable and Drive-CLiQ encoder cable to lock the connector ring. Fix cable to avoid tensile stress. Restore power, run motor identification and positioning test.

Interface

Interface list: Rotatable power connector, Drive-CLiQ encoder connector for HEIDENHAIN 1FK7042-5AF71-1EH2,on-board POWER, COM, FAULT LED indicators.

Diagnostic

Troubleshooting: Motor no movement: Check drive enable signal, power cable and encoder connector. Intermittent positioning alarm: Cable abrasion, poor connector contact or mechanical stuck. Motor overheating: Long time overload, poor ventilation or bearing damage.

Product Brief

Brief description: 1FK7042-5AF71-1EH2 HEIDENHAIN 0.82kW compact synchronous servo motor with Drive-CLiQ absolute encoder,natural cooling,smooth shaft without brake,provides angular position and speed feedback for heavy CNC boring mill feed axis control,servo motor spare.
