GE Fanuc IC3600QSPA103B Turbine Control PCB Board

Technical SpecificationsModel：IC3600QSPA103B Brand：GE Fanuc Product Type: Plug-in printed circuit board for GE Speedtronic Mark I / Mark II gas turbine control rack

Module Feature:Function: Analog signal conditioning, sampling and threshold comparison for turbine protection and monitoring circuit. Process speed, pressure, temperature analog signals from field transducers, generate trip and alarm logic signals for gas turbine safety protection. Multi-channel analog input conditioning circuit Precision reference voltage and comparator circuit Discrete logic gate circuit for protection threshold judgment Gold edge connector for rack backplane connection Component layout: resistors, capacitors, operational amplifiers, logic ICs on PCB Built-in test point terminals for on-site signal measurement No on-board LED, status inspection via external test points Single slot rack mount board, designed for turbine control cabinet

Electrical Parameters:Backplane supply: ±15VDC, +5VDC Signal range: Low level analog transducer signals High common-mode noise rejection for power plant harsh EMI environment

Mechanical & Structure:Mounting: Plug-in installation into Speedtronic Mark I / Mark II rack slot Protection class:IP20 PCB material: High-temperature industrial laminate board

Environmental:Operating temperature:0℃ ~ +65℃ Ambient humidity:5~95% non-condensing Certification:UL, CE approved Status:Manufacturer discontinued legacy spare part

System compatibility

IC3600QSPA103B belongs to GE Fanuc Speedtronic Mark I / Mark II turbine control series. Compatible with Speedtronic Mark I/II control rack, power supply and other signal/protection boards. Widely applied on gas/steam turbine power generation control system.

Function

IC3600QSPA103B is analog signal processing and protection circuit board manufactured by GE Fanuc for old Speedtronic turbine control system. It receives weak analog signals from field transmitters and sensors, performs amplification, filtering and threshold comparison. When measured value exceeds preset limit, it outputs trip or alarm signal for turbine safety protection. Test points on PCB allow maintenance technicians to measure signal level for troubleshooting.

Installation

Follow lockout/tagout safety procedure before installation. Fully cut off turbine control cabinet power. Insert IC3600QSPA103B board into rack slot and lock retainer. Verify all backplane contact pins. Power on, use multimeter at test points to check analog signal and threshold level.

Interface

Speedtronic rack gold-edge backplane connector, field analog signal terminal block, onboard test point terminals for GE Fanuc IC3600QSPA103B.

Feature

Original GE Fanuc IC3600QSPA103B Speedtronic Mark I/II PCB board,precision analog signal conditioning,over-limit protection logic,external test points for maintenance,industrial high anti-EMI PCB design,UL & CE certified. This spare unit is used for power plant gas turbine legacy Speedtronic control cabinet maintenance and hardware replacement.

Diagnostic

No analog signal output:Check rack ±15V / +5V power supply and backplane pin contact. Incorrect threshold comparison:Inspect reference voltage circuit and sensor input wiring. Protection false trip:Troubleshoot signal noise, wiring grounding or component aging.

Product Brief

IC3600QSPA103B is GE Fanuc legacy Speedtronic Mark I/II analog signal processing PCB board,for gas turbine safety monitoring and protection logic,discontinued turbine control spare circuit card.
