Fisher 66R-9 Pressure Regulator

Technical Specifications

Model：66R-9 Brand：Fisher Product Type: Spring diaphragm instrument air pressure regulator

Module Feature

Fisher 66R-9 is small size spring-diaphragm type pressure regulator. It reduces high inlet instrument air pressure to steady preset outlet pressure. Simple and reliable structure with easy local pressure adjustment. It protects downstream pneumatic instruments against pressure surges. Widely used in oil,gas,chemical and power plant control valve pneumatic circuits.

Working principle: Balance between spring force and diaphragm air pressure to maintain constant outlet pressure Onboard components: Diaphragm assembly,adjustment spring,valve plug and seat,adjustment knob,aluminum body,gauge port

LED indicators

Not equipped

Hardware self-diagnosis

Visual inspection,pressure setpoint test,output pressure stability test,air tightness leakage test

Programming software

No dedicated software required

Pneumatic & Mechanical Parameters

Medium:Dry clean instrument air Max inlet pressure:250psi Output pressure range:0~60psi

Mechanical & Structure

Mounting: Pipeline or actuator bracket mounting Protection class:IP66

Environmental

Operating temperature:-40℃ ~ +80℃ Ambient humidity:5~95% non-condensing Certification:CE Status:Fisher 66 series air regulator

System compatibility

Compatible with Fisher DVC series digital valve controllers and pneumatic positioners.

Function

66R-9 is compact air pressure regulator manufactured by Fisher. It stabilizes fluctuating upstream instrument air pressure to fixed output pressure for valve positioner. It guarantees steady air supply to positioner and improves valve control stability. It is standard pneumatic preparation accessory for control valve loop.

Installation

Follow lockout/tagout safety procedure before installation. Isolate instrument air supply. Mount regulator on pipeline or actuator bracket. Connect upstream air tubing. Rotate adjustment knob to set target pressure. Verify pressure stability and air tightness.

Interface

1/4"NPT inlet/outlet air ports,pressure gauge tapping port,mounting lugs,no LED indicators on 66R-9.

Diagnostic

Output pressure drifting: Spring fatigue or diaphragm damage. No air output: Internal seat blocked. Continuous air leakage: Seal aging or loose thread fitting.

Product Brief

66R-9 Fisher compact instrument air pressure regulator,for reducing and stabilizing air supply to valve positioners,small industrial pneumatic control accessory.
