DANAHER MOTION S20660-VTS Servo Drive

Technical SpecificationsModel：S20660-VTS Brand：DANAHER MOTION (Kollmorgen) Product Type: S200 series compact high-performance digital servo amplifier for industrial motion control

Drive Feature: Control mode: Position / Speed / Torque control Command input: Pulse & direction, ±10V analog command Built-in function: Electronic cam, master-slave gearing, homing routine, S-curve acceleration, Smart Feedback Device auto-configuration PWM switching frequency:16kHz

Electrical Parameters: Input voltage: 120/240VAC single phase Continuous output current:6A Peak output current:12A Control power supply:24VDC

Mechanical & Structure: Housing: Compact metal sheet enclosure Mounting: DIN rail mounting Cooling: Convection cooling Protection class: IP20

Environmental: Operating temperature:0℃ ~ +50℃ Ambient humidity:5~85% non-condensing Certification: UL, CE approved Weight: Approx 1.6kg

System compatibility

S20660-VTS belongs to DANAHER MOTION Kollmorgen S200 servo drive family. Compatible with AKM / NSM series Kollmorgen brushless servo motors. Widely used for packaging machinery,material handling and single-axis CNC precision automation equipment.

Function

S20660-VTS is compact digital servo amplifier manufactured by DANAHER MOTION Kollmorgen. It receives motion command signals from upper controller and outputs adjustable drive power to servo motor. Closed-loop control is realized through SFD / encoder feedback to achieve high-precision positioning and fast velocity response. SFD auto recognition simplifies motor parameter setup and commissioning.

Installation

Follow lockout/tagout safety procedure before installation. Mount S20660-VTS on DIN rail inside electrical cabinet. Connect power cable, motor cable and feedback cable strictly follow S200 official wiring manual. Complete motor auto-tuning and motion test during commissioning.

Interface

AC power terminals, motor output terminals, SFD/encoder feedback port, digital I/O terminals, RS232 communication port, status LED indicator for DANAHER MOTION S20660-VTS.

Feature

Original DANAHER MOTION S20660-VTS compact servo drive,small footprint,SFD auto motor detection,high bandwidth current loop,DIN rail installation,convection cooling,UL & CE certified. This spare unit is used for single-axis automation equipment control,motion system maintenance and hardware replacement.

Diagnostic

Drive alarm: Inspect overvoltage,undervoltage,overcurrent and overtemperature faults. Motor no rotation: Check power wiring,SFD/encoder connection and drive enable signal. Positioning deviation: Re-tune servo gain,inspect feedback signal and mechanical backlash. Abnormal vibration: Adjust servo parameters,check motor and coupling alignment.

Product BriefS20660-VTS is DANAHER MOTION Kollmorgen S200 series compact digital servo amplifier,supports multi-mode control,matched with AKM/NSM Kollmorgen brushless servo motors,classic spare part for single-axis industrial precision automation motion system.
