DANAHER MOTION M.1302.8136 Servo Drive

Technical SpecificationsModel：M.1302.8136 Brand：DANAHER MOTION Product Type: M series high-performance digital servo amplifier for industrial motion control

Drive Feature:Control mode: Position / Speed / Torque control Command input: Pulse & direction, ±10V analog command Built-in function: Electronic cam, master-slave gearing, homing routine, S-curve acceleration PWM switching frequency:10kHz

Electrical Parameters:Input voltage: 230VAC single phase Continuous output current:14A Peak output current:28A Control power supply:24VDC

Mechanical & Structure:Housing: Reinforced metal sheet enclosure Mounting: DIN rail mounting Cooling: Forced air cooling Protection class: IP20

Environmental:Operating temperature:0℃ ~ +50℃ Ambient humidity:5~85% non-condensing Certification: UL, CE approved Weight: Approx 2.35kg

System compatibility

M.1302.8136 belongs to DANAHER MOTION M series servo drive family. Compatible with DANAHER MOTION brushless synchronous servo motors and Giddings & Lewis motion controllers. Widely used for medium-heavy packaging equipment,material handling systems and CNC single-axis high-precision motion applications.

Function

M.1302.8136 is high-performance digital servo amplifier manufactured by DANAHER MOTION. It receives motion command signals from upper controller and outputs adjustable high drive power to servo motor. Closed-loop control is realized through encoder feedback to achieve high-precision positioning and fast dynamic response. Built-in electronic cam and master-slave gearing functions support synchronous heavy-load motion control.

Installation

Follow lockout/tagout safety procedure before installation. Mount M.1302.8136 on DIN rail inside electrical cabinet. Connect power cable, motor cable and encoder cable strictly follow DANAHER MOTION M series wiring manual. Complete motor auto-tuning and full-load motion test during commissioning.

Interface

AC power terminals, motor output terminals, encoder port, digital I/O terminals, RS232 communication port, status LED indicator for DANAHER MOTION M.1302.8136.

Feature

Original DANAHER MOTION M.1302.8136 high-power digital servo drive,large continuous & peak current,forced air cooling,DIN rail installation,multiple control modes,UL & CE certified. This spare unit is used for medium-heavy load automation axis drive,motion system maintenance and hardware replacement.
