DANAHER MOTION M.1301.4145 Servo Drive

Technical Specifications

Model：M.1301.4145 Brand：DANAHER MOTION Product Type: High performance digital servo amplifier for industrial motion control

Drive Feature: Control mode: Position / Speed / Torque control Command input: Pulse & direction, serial bus command Built-in function: Electronic cam, homing, S-curve acceleration Switching frequency: 10kHz

Electrical Parameters: Input voltage: 230VAC single phase Continuous output current: 12A Peak output current: 24A Control power: 24VDC

Mechanical & Structure: Housing: Metal enclosure Mounting: DIN rail installation Cooling: Forced air cooling Protection class: IP20

Environmental: Operating temperature: 0℃ ~ +50℃ Ambient humidity: 5~85% non-condensing Certification: UL, CE approved Weight: Approx 2.1kg

System compatibility

M.1301.4145 belongs to DANAHER MOTION servo drive family. Compatible with DANAHER MOTION synchronous servo motors and mainstream PLC systems. Suitable for packaging machinery, material handling and CNC machine tools for single-axis motion control.

Function

M.1301.4145 is digital servo amplifier manufactured by DANAHER MOTION. It receives command signals from upper controller and outputs regulated power to servo motor. Realizes closed-loop control by encoder feedback, achieving high precision positioning and stable speed adjustment. Built-in motion functions simplify machine programming and commissioning.

Installation

Follow lockout/tagout safety procedure before installation. Install M.1301.4145 on DIN rail inside electrical cabinet. Connect power cable, motor cable and encoder cable strictly follow DANAHER MOTION official wiring manual. Complete motor auto-tuning and motion test during commissioning.

Interface

AC power terminals, motor output terminals, encoder port, digital I/O terminals, serial communication port, status LED indicator for DANAHER MOTION M.1301.4145.

Feature

Original DANAHER MOTION M.1301.4145 digital servo drive,multiple control modes,fast dynamic response,DIN rail mount,built-in motion functions,UL & CE certified. This spare unit is used for automation equipment axis control,motion system maintenance and hardware replacement.

Diagnostic

Drive alarm: Inspect overvoltage, undervoltage, overcurrent and overtemperature faults. Motor no rotation: Check power wiring, encoder connection and enable command. Positioning deviation: Re-adjust servo gain, check encoder signal and mechanical backlash. Abnormal vibration: Tune servo parameters, inspect motor and coupling alignment.

Product Brief

M.1301.4145 is DANAHER MOTION high performance digital servo amplifier,supports multi-mode control,matched with Danaher servo motors,classic spare part for industrial automation and CNC motion systems.
