DANAHER MOTION DSA-046-460-S Servo Actuator

Technical Specifications

Model：DSA-046-460-S Brand：DANAHER MOTION Product Type: DSA series rotary servo actuator for industrial valve and damper modulation

Actuator Feature: Output torque: 460 in-lb Shaft diameter: 0.46 inch Rotation angle: 0~90 degree adjustable travel Control signal: 4-20mA analog positioning signal Position feedback: 4-20mA real-time position feedback

Electrical Parameters: Supply voltage: 24VAC Power consumption: Max 21VA Control interface: Analog 4-20mA command and feedback loop Positioning repeatability: ±0.2°

Mechanical & Structure: Gearbox: High strength metal gear assembly Housing: Die cast aluminum enclosure Mounting: Standard foot mounting, compatible with mechanical linkage Manual override: Manual handwheel for stroke adjustment during commissioning

Environmental: Operating temperature: -40℃ ~ +85℃ Ambient humidity:0~85% non-condensing Certification: UL, CE approved Weight: Approx 3.6kg

System compatibility

DSA-046-460-S belongs to DANAHER MOTION DSA servo actuator family. Compatible with mainstream analog motion controllers and PLC systems. Designed for industrial automation, HVAC and process control applications. Used to drive air dampers and control valves.

Function

DSA-046-460-S is rotary servo actuator manufactured by DANAHER MOTION. It receives 4-20mA positioning command signal from controller and rotates output shaft to target angle. Built-in position feedback transducer sends actual shaft position back to controller for closed-loop control. The handwheel allows manual operation for stroke setting and maintenance. It adjusts damper or valve to maintain accurate positioning for process control applications.

Installation

Follow lockout/tagout safety procedure before installation. Mount DSA-046-460-S on machine or valve frame. Connect mechanical linkage to damper or valve shaft. Wire 24VAC power and 4-20mA command/feedback cables strictly follow DANAHER MOTION DSA series wiring manual. Perform full stroke calibration and linkage test during commissioning.

Interface

0.46" output shaft,24VAC power terminals,4-20mA command input,4-20mA position feedback,manual handwheel,aluminum actuator housing for DANAHER MOTION DSA-046-460-S.

Feature

Original DANAHER MOTION DSA-046-460-S heavy-duty rotary servo actuator,460in-lb high torque,0.46 inch shaft,4-20mA closed loop positioning,manual override,UL & CE certified. This spare unit is used for industrial damper / valve modulation,automation equipment maintenance and hardware replacement.

Diagnostic

Actuator no movement: Inspect 24VAC power supply,control wiring and command signal. Position deviation: Calibrate stroke endpoints,check mechanical linkage binding or slack. No position feedback: Verify feedback wiring,internal sensor damage. Jitter or hunting: Check linkage friction,electrical noise interference.

Product Brief

DSA-046-460-S is DANAHER MOTION DSA series high torque rotary servo actuator with 460in-lb torque and 0.46in shaft,for air damper and process valve modulation,matching mainstream analog controllers,classic spare for industrial automation motion system.
