DANAHER MOTION 5010430600 Servo Motor

Technical Specifications

Model：5010430600 Brand：DANAHER MOTION Product Type: Permanent magnet brushless rotary servo motor for industrial CNC motion control

Motor Feature: Motor type: Brushless permanent magnet synchronous motor Feedback device: Built-in incremental encoder Output characteristic: Low torque ripple,high continuous torque,strong overload capacity Rotation direction: CW / CCW reversible

Electrical Parameters: Rated voltage: 230VAC Rated speed: 3000 rpm Rated torque: 7.2 Nm Rated current: 8.4A

Mechanical & Structure: Shaft: Keyway output shaft Housing: Reinforced cast aluminum alloy housing Mounting: Flange mounting Protection class: IP65

Environmental: Operating temperature: -20℃ ~ +40℃ Ambient humidity:0~85% non-condensing Certification: UL, CE approved Weight: Approx 5.6kg

System compatibility

5010430600 belongs to DANAHER MOTION servo motor family. Compatible with DANAHER M-series digital servo drives and Giddings & Lewis motion controllers. Widely applied in heavy-duty CNC lathes, milling machines and material handling automation systems.

Function

5010430600 is brushless permanent magnet servo motor manufactured by DANAHER MOTION. It converts electric energy into precise rotary mechanical power controlled by servo amplifier. Integrated incremental encoder transmits real-time position and speed signals for closed-loop control, delivering stable high torque output for heavy load motion axis.

Installation

Follow lockout/tagout safety procedure before installation. Mount motor flange firmly on machine base. Connect power cable and encoder feedback cable strictly follow DANAHER MOTION wiring manual. Complete mechanical alignment, homing calibration and running test during commissioning.

Interface

Power connector,encoder feedback connector,keyway shaft,flange mounting holes,cast aluminum housing for DANAHER MOTION 5010430600.

Feature

Original DANAHER MOTION 5010430600 brushless servo motor,high torque density,strong overload resistance,IP65 protection,rugged industrial construction,UL & CE certified. This spare unit is used for heavy-load CNC machine axis drive,motion control system maintenance and hardware replacement.

Diagnostic

Motor no rotation: Inspect servo drive enable signal,power wiring and encoder connection. Abnormal noise: Check coupling alignment,bearing wear and mechanical binding. Overheat alarm: Evaluate equipment load,ambient temperature and ventilation condition. Position drift: Check encoder wiring,shield grounding and mechanical backlash.

Product Brief

5010430600 is DANAHER MOTION heavy-duty permanent magnet brushless AC servo motor,matched with Danaher M series servo drive system,classic spare component for CNC machine tools and high-load industrial automation.
