BAUMULLER 12 Poles Servo Motor Encoder Connector

Technical Specifications

Model: 12 POLES CONNECTOR Brand: BAUMULLER (Baumüller, Germany) Product Type: 12-pole circular connector for servo motor encoder/resolver feedback Housing: Metal shell, threaded locking structure Pin count: 12 poles Mounting: Mounted on BAUMULLER servo motor rear end Operating temperature: -20℃ ~ +80℃ Storage temperature: -25℃ ~ +85℃ Relative humidity: 5%~95%, non-condensing Protection: IP67 when fully locked Weight: 0.18kg Dimension: M23 circular form

System compatibility

This 12 poles connector is matched with BAUMULLER servo motors and b maXX series drives. It serves as feedback interface for printing, textile and metal forming machinery servo systems.

Function

12-pole circular connector for motor feedback circuit. It transmits resolver position signals, temperature sensor signals and brake control signals between servo motor and drive cable. The threaded locking design ensures stable contact under machine vibration, prevents signal dropout. It is used to replace aged, cracked or corroded original plugs during motor overhaul.

Installation

Disconnect all power supply before operation. Unlock the old connector and detach cable assembly. Install 12 poles connector, crimp wires strictly following pin assignment, tighten thread lock. Check shielding continuity, test motor closed-loop operation before formal production.

Interface

12 contact pins, metal locking thread, shield connection terminal for BAUMULLER 12 poles connector.

Feature

BAUMULLER original circular feedback plug, 12 signal pins, IP67 sealing, anti-vibration threaded lock, integrated shielding connection, high temperature resistance, industrial anti-interference design. This spare part used for old BAUMULLER servo motor feedback wiring maintenance and replacement.

Diagnostic

Feedback signal lost: check pin crimp quality and thread locking status for 12 poles connector. Unstable motor position: inspect shielding wiring and pin corrosion. Intermittent drive alarm: verify connector sealing and cable strain relief.

Product Brief

12 POLES CONNECTOR is German BAUMULLER 12-pole circular connector for servo motor feedback. It transfers resolver and temperature signals for closed-loop motion control, classic spare part for legacy BAUMULLER servo equipment overhaul.

Disclaimer: All parameters are for reference only and shall not be used as the basis for quotation. Goods are scarce, overseas delivery lead time is 3-7 working days. It is only used for equipment maintenance and renovation.
