Banner MAHE6A Light Curtain Emitter Unit

Module Feature

MAHE6A belongs to Banner MINI-ARRAY high precision measuring light curtain series. It is the infrared emitter unit,matched with corresponding receiver and control module. 163mm effective array length,64 beams with 2.5mm beam pitch. Dual staggered infrared LED columns realize high resolution object detection. Aluminum extrusion housing,compact slim profile. Widely used for on-the-fly dimension measurement,edge guiding,web tension control,hole inspection and parts counting on automated machinery.

Working principle

Emitter transmits infrared beam array to receiver. When object interrupts beams,the system calculates blocked beam position to get workpiece size or edge position. Real-time measurement data is sent to PLC or host controller for closed-loop process adjustment. Built-in circuit monitors power and LED status.

Onboard components

Infrared LED array,drive circuit,signal processing PCB,aluminum housing,status LED,quick-disconnect M12 connector.

LED indicators

Power LED,fault LED,beam status indicator.

Hardware self-diagnosis

Power supply monitoring,LED array self-check,communication link diagnosis,over temperature protection.

Programming software

Banner MINI-ARRAY configuration software,used for parameter setup,diagnostic reading and measurement tuning.

Electrical & Process Parameters

Model:MAHE6A Brand:Banner Device type:MINI-ARRAY Measuring Light Curtain Emitter Effective array length:163mm Beam quantity:64 Beam resolution:2.5mm Power supply:12VDC Sensing range:0.38 ~ 1.8 m Housing material:Aluminum Cooling:Natural convection cooling Protection:Reverse polarity,over temperature protection

Mechanical & Structure

Mounting:Slot mounting Protection class:IP65 Housing:Extruded aluminum housing

Environmental

Operating temperature:0℃ ~ +50℃ Storage temperature:-40℃ ~ +85℃ Ambient humidity:5~95% non-condensing Certification:CE,cRUus,RoHS compliant Status: Banner original MINI-ARRAY high resolution measuring light curtain emitter

Installation

Follow strict ESD safety procedure before handling.Mount emitter and receiver on parallel mounting brackets,align optical axis.Connect 12VDC power and control cable via M12 connector,complete commissioning with configuration software.

Interface

M12 quick-disconnect connector,mounting slot interface.

Diagnostic

No beam output:power loss or LED array damage. Measurement unstable:poor optical alignment or dust contamination on lens. Fault alarm:over temperature or internal circuit failure.

Product Brief

Banner MAHE6A MINI-ARRAY measuring light curtain emitter,163mm 2.5mm resolution 64 beams,12VDC supply,used for online dimension measurement,edge guiding and part inspection in automation production lines.
