Yaskawa JANCD-5TU0 Interface Board

Technical Specifications

Model:JANCD-5TU0

Brand:Yaskawa

Product type:Yasnac CNC interface PCB board

Power supply:DC24V

Control function:External device signal conversion,parallel signal transmission,peripheral unit data exchange,signal level conversion and noise filtering

Communication:System backplane bus

Mounting:Rack mount

Operating temperature:0~55℃

Relative humidity:5~95% non-condensing

Weight:0.41kg

Certification:CE

System compatibility

JANCD-5TU0 belongs to Yaskawa Yasnac CNC controller family,matched with vintage Yasnac CNC systems. Widely used in old CNC lathes and milling machines. This is a discontinued legacy interface board for old machine tool maintenance spare replacement.

Function

JANCD-5TU0 serves as high precision CNC interface board. It converts different electrical level signals between CNC main unit and external peripheral equipment,realizes reliable data exchange. Built-in signal filtering and surge protection circuit to suppress workshop interference. It acts as signal bridge for CNC host and peripheral components.

Installation

Mount JANCD-5TU0 inside CNC controller cabinet. Complete backplane bus and external equipment wiring according to wiring drawing. Check cable integrity before power-up,verify signal communication between CNC and peripheral devices after power on.

Interface

‑System backplane bus connector

‑External peripheral signal port

‑Signal conversion terminal

‑Onboard signal filtering and protection circuit

Circuit feature

Compact rugged PCB layout,equipped with surge and ESD suppression circuit. Stable signal transmission,strong anti-interference performance for industrial cabinet environment.

Feature

JANCD-5TU0 is obsolete Yaskawa Yasnac series spare part. Typical failures include port pin oxidation,signal attenuation,intermittent communication. Check board integrity and connector pins before replacement. This board must match corresponding Yasnac CNC controller,direct substitution without signal communication test is not recommended.

Diagnostic

When peripheral communication dropout,signal distortion or hardware timeout occurs,the board triggers alarm codes and sends fault signal to CNC main controller.

Built‑in function

Peripheral signal level conversion,CNC and external device data exchange,signal noise filtering,communication fault monitoring,used as Yasnac CNC interface board spare replacement.

Product Brief

JANCD-5TU0 is Yaskawa Yasnac CNC series interface board for CNC machine tools and precision automation equipment. Confirm CNC controller model matching before ordering. ESD protection required during handling and installation.
