XYCOM PM9450 Industrial Processor Module

Technical Specifications

Model:PM9450

Brand:XYCOM

Product type:VMEbus Real-time Processor Control Board

Power supply:+5V VME backplane power

Bus interface:Standard VMEbus,support master/slave communication

Form factor:Single-height VME card

Weight:0.28kg

Operating temperature:0℃ ~ +50℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~95%,non-condensing

Certification:CE,UL

System compatibility

PM9450 belongs to XYCOM PM series VME processor board.

It installs in XYCOM VME chassis and cooperates with XVME series I/O modules.

Compatible with turbine,compressor and legacy DCS control systems via VME bus.

Commonly used for power plant,oil & gas,petrochemical old equipment maintenance and spare replacement.

Function

Serve as core processing unit for VME rack control system.

Execute real-time control logic and process algorithm calculation.

Process field collected analog and digital signals,output control instructions.

Data exchange and bus management with each I/O board through VME backplane.

Onboard self-test for processor core,onboard memory and VME bus interface fault inspection.

Installation

Power off VME chassis.

Insert PM9450 card into empty VME slot,tighten front panel fixing screw.

Check backplane connection status.

Power on chassis,run hardware self-test.

System recognizes the processor board and starts real-time control operation.

Interface

VME P1 backplane connector,LED indicators:PASS,FAULT,RUN.

Feature

Single height VME processor board,XYCOM PM series core controller.

Industrial grade processor chip,stable real-time computing performance.

Support VME master/slave dual mode,flexible system configuration.

Built-in EMC protection,resist complex industrial electromagnetic interference.

Discontinued obsolete VME module,supply only for old production system spare replacement.

Vibration resistant PCB design,suitable for turbine control cabinet.

Diagnostic

FAULT LED on:processor core failure or memory damage;

Cannot be identified by system:check VME backplane contact and address jumper setting;

Control logic abnormal:check board power supply and firmware status.

Product Brief

XYCOM PM9450 is legacy VMEbus real-time processor control board.

It acts as core controller of VME rack to complete real-time operation of process control logic,widely used as spare part for turbine and compressor control,petrochemical and power plant old DCS renovation.
