STASTO MV46 Pneumatic Manual Valve

Feature & Principle

MV46 is STASTO series 3/2 way manual toggle pneumatic valve. It adopts bistable rocker structure, switching air circuit pressurization and depressurization. The valve body is nickel-plated brass, with stable sealing performance, quick response and small operating force. It is widely used for local manual air path switching in automation fixtures and pneumatic equipment.

Specifications

Model: MV46 Brand: STASTO Function: 3/2 NC bistable rocker Pressure range: 0~15 bar Flow rate: 235 Nl/min Port: G1/8" DN: 2.5 mm Body material: Nickel-plated brass Temperature: -20 ~ +80℃ Application: Automation fixture, pneumatic machinery air circuit Certification: CE

Components & Diagnostics

Brass valve body, rocker actuator, internal spool, sealing rings, thread connector. Common faults: seal aging air leakage, spool stuck, rocker position failure.

Product Brief

MV46 pneumatic toggle valve, STASTO manual air control spare widely used for automation fixture overhaul and replacement.
