SIEB & MEYER 0610520 CNC 61.00 Encoder Feedback Cable

Module Feature

SIEB & MEYER 0610520 CNC 61.00 is pre-terminated shielded high-flex encoder feedback cable. It is designed to transmit high-resolution position and speed feedback signals from servo motor encoder to SIEB & MEYER axis control board. Twisted pair signal structure with full copper braid shielding, excellent noise immunity against IGBT switching interference. Oil-resistant and wear-resistant outer sheath, suitable for continuous bending inside drag chain. Both ends equipped with precision molded signal connectors. Widely used in CNC machine tools, semiconductor processing equipment and precision inspection automation lines.

Working principle

Transmits differential encoder position and speed feedback signals from motor encoder to axis control board. Twisted-pair design suppresses common-mode noise, and overall shielding blocks electromagnetic interference generated by servo power cables. Reliable signal transmission ensures stable closed-loop position control of servo axis.

Onboard components

Twisted pair signal conductors, copper braided shielding layer, oil resistant outer jacket, molded metal signal connectors, strain relief protection.

LED indicators

No LED indicators.

Hardware self-diagnosis

Visual inspection of cable jacket abrasion, cracks and connector damage; continuity test of each signal core; insulation resistance test; check shield continuity and grounding quality.

Programming software

No dedicated configuration software.

Electrical & Process Parameters

Model: 0610520 CNC 61.00 Rated voltage: 300V Conductor: Multi-strand flexible copper twisted pair Shield: Copper braid shield Bending characteristic: High flex for drag chain Cooling: Natural ambient Protection: Oil resistant, abrasion resistant Mounting: Cable tray / drag chain routing

Mechanical & Structure

Mounting: Cable tray / drag chain routing Protection class: IP67 when connectors fully mated

Environmental

Operating temperature: -20℃ ~ +80℃ Ambient humidity: 5~95% non-condensing Certification: CE compliant Status: SIEB & MEYER high flex encoder feedback cable assembly

System compatibility

Compatible with SIEB & MEYER servo axis control boards and matched servo motors, used for encoder feedback signal transmission in CNC and semiconductor servo systems.

Function

0610520 CNC 61.00 encoder feedback cable manufactured by SIEB & MEYER. It delivers differential encoder feedback signals from motor to axis controller to realize closed-loop servo positioning. Broken wires, loose connectors or poor shield grounding will trigger encoder loss alarm and servo shutdown. It is critical signal cable for high precision servo motion control system.

Installation

Follow lockout/tagout safety procedure before installation. Cut off all system power completely. Route cable inside drag chain or cable tray, maintain minimum bending radius, avoid sharp edges. Connect two end connectors to motor encoder and axis control board correctly, ensure shield grounding. Power on and verify encoder signal before formal operation.

Interface

Motor encoder connector, axis control board signal connector, shield grounding terminal of 0610520 CNC 61.00.

Diagnostic

No encoder signal: Broken signal wire, loose connector or wrong pin assignment. Intermittent position error: Poor shield ground, cable fatigue or connector vibration loose. Encoder fault alarm: Short circuit between signal cores or cable insulation damage. Position jitter: Electromagnetic interference from adjacent power cables. Jacket damage: Mechanical abrasion in drag chain.

Product Brief

0610520 CNC 61.00 SIEB & MEYER high flex shielded encoder feedback cable,300V rated voltage,pre-terminated connectors,for transmitting motor position feedback signal between servo motor and axis control board in CNC and semiconductor high precision motion control.
