SIEB & MEYER 021807102X Spindle Frequency Converter

Module Feature

SIEB & MEYER part number 021807102X belongs to FC80 series rack plug-in high-frequency spindle frequency converter. It is designed to drive high-speed synchronous spindle motors with encoder feedback. It supports high output frequency for ultra-high spindle rotation speed, featuring fast dynamic response, stable speed regulation and low torque ripple. Equipped with multi-level current, voltage and temperature monitoring protection circuit. Compact rack plug-in structure with reliable EMC performance. Widely used in PCB routing, CNC milling and semiconductor drilling equipment. This model is discontinued legacy drive.

Working principle

Single-phase AC input passes EMI filter and rectifier circuit and converts into DC bus. IGBT power stack converts DC bus into adjustable amplitude high-frequency three-phase AC to drive spindle motor. It continuously collects encoder speed and position feedback signal to realize closed-loop speed and spindle orientation control. Once abnormal condition detected, the drive cuts off power output immediately and sends fault signal to rack control system for safety interlock.

Onboard components

IGBT power stack, DC-link capacitor bank, current sampling circuit, encoder feedback interface, control processor, temperature sensor, power terminal block, gold finger backplane connector, LED status indicator array.

LED indicators

Front panel LED indicators for module power, drive ready, spindle enable, running status and fault code display.

Hardware self-diagnosis

Visual inspection of module housing, terminals and backplane gold fingers; DC bus voltage measurement; spindle motor cable insulation and continuity test; read LED fault codes; inspect cooling fan and heat sink for dust accumulation.

Programming software

SIEB & MEYER commissioning software for spindle parameter configuration, speed auto-tuning and fault log reading.

Electrical & Process Parameters

Model: 021807102X (FC80 series) Device type: High frequency spindle frequency converter Input: 1 phase AC mains Output: High frequency 3-phase AC for synchronous spindle motor Control mode: Closed loop speed / orientation control Cooling: Forced air cooling with built-in fan Protection: Overvoltage, undervoltage, overcurrent, short circuit, overtemperature protection Mounting: Rack plug-in mounting

Mechanical & Structure

Mounting: Rack plug-in mounting Protection class: IP20 (inside control cabinet)

Environmental

Operating temperature: 0℃ ~ +50℃ Ambient humidity: 5~95% non-condensing Certification: CE compliant Status: SIEB & MEYER legacy FC80 spindle frequency converter

System compatibility

Compatible with SIEB & MEYER rack power supply and synchronous spindle motors, forms complete high-speed spindle drive system for CNC and semiconductor processing equipment.

Function

021807102X frequency converter manufactured by SIEB & MEYER. It outputs high-frequency three-phase AC power to drive synchronous spindle motor and maintain precise spindle speed and angular positioning. Motor overload, cable short-circuit, fan failure or capacitor aging will trigger protection and disable power output. It is spindle power amplifier unit for SIEB & MEYER rack CNC system.

Installation

Follow lockout/tagout safety procedure before installation. Cut off all rack power completely. Insert module into designated rack slot and lock handle securely, confirm stable backplane contact. Wire spindle power cable and encoder feedback cable correctly. Configure spindle parameters and perform auto-tuning via SIEB & MEYER commissioning software, test spindle rotation before formal operation.

Interface

Single-phase AC input terminal, spindle motor 3-phase power output terminal, encoder feedback connector, backplane bus connector, fault signal output terminal of 021807102X.

Diagnostic

No power LED: Missing AC input, blown input fuse or input wiring fault. Drive not ready: Pre-charge fault, damaged DC capacitor or backplane communication error. Overcurrent alarm: Spindle motor winding short, damaged power cable or mechanical jam. Overheat alarm: Cooling fan failure, clogged heat sink or high ambient temperature. Speed deviation fault: Damaged encoder, loose feedback cable or incorrect parameter setting.

Product Brief

021807102X SIEB & MEYER FC80 rack plug-in high speed spindle frequency converter,high frequency AC output,for encoder equipped synchronous spindle motors,used in CNC machine and semiconductor routing & drilling equipment.
