Schneider M3P110ASAB00 Motor Protection Circuit Breaker

Feature & Principle

It integrates thermal overload protection and magnetic short-circuit protection. The thermal element responds to long-time overload current, while the magnetic element trips instantly when short circuit occurs. It can directly protect three-phase asynchronous motors, compact structure, easy DIN rail mounting, and can be matched with contactors to form a complete motor starter.

Specifications

Model: M3P110ASAB00 Brand: Schneider Electric Pole: 3P Rated current: 110 A Trip type: Thermal magnetic Mounting: DIN rail Rated voltage: 690 V AC Frequency: 50/60Hz Standard: IEC 60947-2 Application: Fan, pump, conveyor motor protection Certification: CE

Components & Diagnostics

Bimetallic thermal element, magnetic trip coil, contact group, arc extinguishing chamber, operating handle. Common faults: false tripping under normal load, contact overheating, trip unit failure, handle stuck.

Product Brief

M3P110ASAB00 motor protection circuit breaker, Schneider electrical spare widely used for industrial pump, fan and conveyor motor control cabinet maintenance and replacement.
