Rexroth CS351S-G Tightening Compact Controller

Feature & Principle

It is an integrated compact tightening controller for single tightening spindle. It integrates servo drive, power unit and control logic. It realizes closed-loop torque and angle control for bolt assembly. The built-in touch TFT screen can display tightening curve and result data. It supports Ethernet bus communication to connect with upper PLC, with self-diagnosis function to guarantee assembly quality for safety-critical production lines.

Specification

sModel: CS351S-G Brand: Rexroth Bosch Order number: 0608830255 Screen: High resolution TFT touch display Weight: 9.7 kg Protection grade: IP54 EMC class: IV Interface: Ethernet, USB Controlled object: Tightening spindle Application: Automotive assembly, precision bolt fastening Certification: CE

Components & Diagnostics

Main control board, servo power module, TFT touch display, status indicator, communication terminal. Common faults: touch screen failure, communication drop, tightening torque deviation, drive alarm, power abnormal.

Product Brief

CS351S-G tightening controller, Rexroth precision assembly spare widely used for automobile workshop and automated bolt tightening station maintenance and replacement.
