Rexroth CLMFWA-CLM1.4 Firmware Module Spare Part

Technical Specifications

Model:CLMFWA-CLM1.4

Brand:Rexroth

Part No:R911288345

Product type:firmware flash module for CLM1.4 positioning controller

Input voltage:24V DC control power

Dimension:80mm130mm20mm

Weight:0.28kg

Communication:bus interface matching CLM1.4 controller

Mounting:Plug-in slot installation

Protection class:IP20

Operating temperature:0~45℃

Storage temperature:-20~70℃

Relative humidity:5~95% non-condensing

Certification:CE

LED indicators:Power,Status

System compatibility

CLMFWA-CLM1.4 belongs to Rexroth Indramat CLM control family,specially compatible with CLM1.4 series positioning control modules,widely used in packaging machinery,robotics,textile machines and material handling equipment.This is a legacy spare part for industrial equipment maintenance replacement.

Function

CLMFWA-CLM1.4 is a pluggable firmware flash module for CLM1.4 series positioning controllers.It stores the core motion control firmware,responsible for axis positioning logic,program operation and parameter management.It supports firmware upgrade,backup and recovery for CLM1.4 controller.

Installation

Insert CLMFWA-CLM1.4 into the dedicated slot of CLM1.4 controller.Ensure power off before plug-in.Check contact terminals and restart controller after installation to finish firmware loading.

Interface

‑Internal bus gold finger connector

‑Status indicator LED

‑Shield grounding terminal

Circuit feature

High-speed flash storage circuit,built-in write protection circuit,anti-surge design,supports firmware read/write and data storage,stable for long-term industrial operation.

Feature

CLMFWA-CLM1.4 is obsolete Rexroth spare part.Typical faults:flash chip damage,contact oxidation,firmware corruption,data loss.Inspect connector contacts and verify firmware version before replacement.Backup controller parameters before disassembly.

Diagnostic

When module fails,Power LED abnormal,Status LED flashing error code,controller cannot boot,fails to load motion program,axis unable to initialize.

Built‑in function:Store CLM1.4 controller motion firmware,support firmware upgrade,parameter backup and recovery,used as Rexroth Indramat CLM series controller spare replacement.

Product Brief

CLMFWA-CLM1.4 is Rexroth Indramat plug-in flash firmware module dedicated for CLM1.4 positioning controller.It can restore or upgrade controller firmware.Verify model matching before ordering.ESD protection required during handling and installation.
