Rexroth 112C-0-ED-1-B/130-A-1/1625/S05 Spare Part

Technical Specifications

Model:112C-0-ED-1-B/130-A-1/1625/S05

Brand:Rexroth

Product type:Hydraulic solenoid valve

Power supply:130V DC

Control function:Hydraulic oil on-off switching,flow cut-off,coil overheat protection,mechanical self-diagnosis

Communication:No digital bus

Mounting:Manifold block mounting

Operating temperature:-20~80℃

Storage temperature:-25~85℃

Relative humidity:5~95% non-condensing

Max working altitude:2000m

Weight:1.02kg

Dimension:140mm75mm70mm

Certification:CE

Protection class:IP65

System compatibility

112C-0-ED-1-B/130-A-1/1625/S05 belongs to Rexroth hydraulic valve series,matched with manifold block,hydraulic pump and hydraulic actuator.Widely applied in automation production line,press equipment and hydraulic power unit workstations.This is a discontinued legacy spare part for equipment maintenance replacement.

Function

112C-0-ED-1-B/130-A-1/1625/S05 is Rexroth hydraulic solenoid valve for industrial hydraulic circuits.It uses electromagnetic coil to drive valve spool movement to switch hydraulic oil flow direction and realize circuit on-off.It can cut off or connect hydraulic medium flow according to electrical control signal.It integrates coil overheat protection to avoid burnout under long-time energization.It feeds back valve working state for system monitoring.It acts as fluid on-off execution component for industrial hydraulic workstation.

Installation

Install 112C-0-ED-1-B/130-A-1/1625/S05 onto manifold valve block and tighten fixing bolts.Ensure oil flow direction matches the marking on valve body.Connect 130V DC coil wiring according to wiring drawing.Check sealing performance and oil cleanliness before system power-on.

Interface

‑130V DC coil power terminal

‑Hydraulic oil inlet port

‑Hydraulic oil outlet port

‑Spool status indicator

Circuit feature

Built-in coil surge suppression circuit,anti-pollution spool design,stable switching performance under industrial hydraulic working environment.

Feature

112C-0-ED-1-B/130-A-1/1625/S05 is obsolete Rexroth spare part.Typical faults:valve fails to switch,coil burnout,internal oil leakage,spool stuck.Inspect coil,valve spool and sealing gasket before replacement.This valve must match corresponding hydraulic medium and working pressure,direct substitution without inspection is not recommended.

Diagnostic

When coil damage,spool jam or sealing failure occurs,the system will report hydraulic control abnormal alarm.

Built‑in function:Hydraulic circuit on-off control,coil overheat protection,spool direction switching,used as hydraulic control system spare replacement.

Product Brief

112C-0-ED-1-B/130-A-1/1625/S05 is Rexroth old hydraulic solenoid valve for industrial hydraulic workstation.Confirm working pressure and hydraulic oil medium before ordering.ESD protection required during handling and installation.
