RELIANCE 0-52807 Tach Loss Overspeed Protection Board

Technical SpecificationsModel:0-52807 Brand:RELIANCE Product type:Tach Loss Overspeed Protection Board Weight:0.52kg Dimension:210mm135mm30mm Operating temperature:0℃ ~ 60℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~85%,non-condensing Certification:CE

System compatibility0-52807 is RELIANCE rack plug-in tach loss overspeed protection board. It is designed for Reliance MaxPak Plus series spindle DC drive rack,cooperates with ARM armature regulator board and speed feedback board. It continuously monitors tachometer or encoder speed signal,detects feedback loss and overspeed condition,triggers safety shutdown to protect spindle motor and mechanical equipment. Commonly used for maintenance and spare replacement of old industrial spindle DC drive equipment.

Function0-52807 is dedicated tach loss overspeed protection PCB for RELIANCE MaxPak Plus DC drive system. Receive speed feedback signal from tachometer,encoder or resolver board. Real-time signal comparison and threshold judgment. When tach signal missing or motor speed exceeds preset limit value,this board outputs fault interlock signal to cut off drive output. Front panel multi-turn potentiometers for overspeed threshold and signal timeout setting. Dual LED indicators display board power and fault alarm status. Built-in signal noise filter to prevent false protection triggered by transient pulse interference.

InstallationPower off the whole drive cabinet and cut main power supply. Insert 0-52807 protection board into drive rack slot and lock retaining screw. Connect gold finger backplane connector for speed signal and interlock signal transmission. Separate speed feedback wiring from high power pulse cables. Power on system,set overspeed limit and tach loss timeout via potentiometers. Perform function test to verify protection action under overspeed and signal loss condition.

InterfaceBackplane edge connector,speed feedback signal input,fault interlock output,auxiliary power terminal,shield grounding terminal,dual status LED indicators,front multi-turn calibration potentiometer bank.

FeatureRELIANCE 0-52807 rack mount tach loss overspeed protection board. Real-time speed monitoring and safety interlock circuit for spindle drive. Front panel adjustable potentiometers for protection threshold setup. Noise filter circuit to avoid false trip. Gold plated edge connector for reliable rack signal transmission. Dual LED visual indication for power and fault alarm state. Industrial PCB design for long continuous running in harsh factory environment. Discontinued obsolete board,supply only for old Reliance MaxPak Plus DC drive system spare replacement. Suitable for metallurgy,paper-making production line spindle DC drive renovation and maintenance.

DiagnosticDrive false overspeed trip:signal noise or threshold potentiometer drift; No protection action when speed over limit:input circuit damage or parameter mis-setting; LED no light:board auxiliary power loss; Random fault alarm:poor shielding or ground potential difference; Intermittent protection trigger:backplane pin oxidation and poor contact.

Product BriefRELIANCE 0-52807 is tach loss overspeed protection board. It monitors spindle speed feedback signal,detects tachometer loss and overspeed fault,and sends safety interlock signal for Reliance MaxPak Plus legacy spindle DC drive protection,widely used as spare part for legacy DC drive equipment maintenance.
