RELIANCE 0-49011-6A Driver Board

Technical Specifications Model:0-49011-6A Brand:RELIANCE Product type:Driver Board Weight:1.12kg Dimension:231mm161mm28mm Operating temperature:0℃ ~ 60℃ Storage temperature:-40℃ ~ +85℃ Relative humidity:5%~85%,non-condensing Certification:CE

System compatibility 0-49011-6A belongs to RELIANCE CardPak series SCR pulse driver board. Installed into CardPak rack,works with regulator board and transductor board. It generates and amplifies SCR gate trigger pulses for CardPak DC drive power unit. Commonly used for old industrial DC drive equipment maintenance and spare replacement.

Function 0-49011-6A is dedicated SCR pulse driver board for RELIANCE CardPak DC drive system. Receive firing angle command signal from main regulator board. Generate isolated,amplified gate trigger pulses for silicon controlled rectifiers. Control SCR turn-on timing to adjust DC output voltage of drive. Provide galvanic isolation between low voltage control circuit and high voltage SCR power stage. Monitor pulse output status and feed fault signal back to regulator. Suppress pulse interference to avoid false triggering of power thyristors.

Installation Power off the whole drive cabinet and cut main power supply. Insert 0-49011-6A board into designated CardPak slot and lock retaining latch. Connect backplane bus connector and SCR gate pulse wiring. Separate low voltage control wiring from high power main circuit cable. Power on system,check pulse output waveform. Test drive start and speed regulation under no-load and load condition.

Interface Backplane bus connector,pulse signal output terminal,status & fault LED indicators.

Feature RELIANCE 0-49011-6A,CardPak rack mount SCR pulse driver board. Isolated high-current gate pulse generation for SCR. Precise firing angle control for DC drive voltage regulation. Built-in pulse monitoring and fault feedback circuit. Industrial PCB design for long continuous running in harsh factory environment. Discontinued obsolete board,supply only for old CardPak DC drive system spare replacement. Suitable for metallurgy,paper-making production line DC drive renovation.

Diagnostic Drive no DC output:no trigger pulse or SCR gate circuit damage; Motor speed unstable:pulse jitter caused by component aging; SCR phase imbalance:partial pulse channel loss; Drive overheating:incorrect pulse amplitude; Regulator board firing fault alarm:driver board pulse output abnormal.

Product Brief RELIANCE 0-49011-6A is CardPak SCR pulse driver board. It receives firing command and generates isolated trigger pulses for SCR power components of Reliance CardPak DC drive,widely used as spare part for legacy DC drive equipment maintenance.

Disclaimer All parameters are for reference only and not the basis of quotation. Goods are scarce,overseas delivery lead time 3-7 working days. It is only used for equipment maintenance and retrofit.
