RELIANCE 0-48652 Calibration Meter Board

Technical Specifications

Model:0-48652

Brand:RELIANCE

Product type:Calibration Meter Board

Weight:1.35kg

Dimension:235mm165mm30mm

Operating temperature:0℃ ~ 60℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~85%,non-condensing

Certification:CE

System compatibility

0-48652 belongs to RELIANCE MAXPAK+ spindle drive series calibration meter board.

Installed into MAXPAK+ spindle drive cabinet,works with spindle regulator board and power unit.

It is the speed parameter calibration and signal adjustment unit for spindle drive system.

Commonly used for old industrial spindle drive equipment maintenance and spare replacement.

Function

0-48652 is dedicated calibration meter board for RELIANCE MAXPAK+ spindle drive system.

Provide multi potentiometer knobs for spindle speed,balance and zero point manual calibration.

Tweak tachometer feedback signal and speed ratio parameter.

Real-time signal monitoring for spindle closed-loop regulation circuit.

Assist to set maximum speed and automatic speed limit value.

Adjust signal offset to eliminate speed drift error.

Display reference signal status during drive commissioning.

Installation

Power off the whole spindle drive cabinet and cut main power supply.

Insert 0-48652 board into designated rack slot and lock retaining latch.

Connect backplane bus and analog feedback signal wiring.

Separate low voltage signal wiring from high power main circuit cable.

Power on system,enter drive commissioning mode.

Adjust potentiometer knobs to complete spindle speed calibration.

Interface

Backplane bus connector,tachometer feedback signal terminal,adjustment potentiometer knobs,signal status LED indicators.

Feature

RELIANCE 0-48652,MAXPAK+ spindle calibration meter board.

Multiple adjustable dials for speed and balance parameter setting.

Onboard signal monitoring circuit for drive commissioning.

Optimize closed-loop feedback signal to stabilize spindle rotation.

Industrial PCB design for long continuous running in harsh factory environment.

Discontinued obsolete board,supply only for old spindle drive system spare replacement.

Suitable for machine tool spindle drive renovation.

Diagnostic

Spindle speed drift:calibration parameter offset or potentiometer aging;

Unable to adjust speed:signal terminal loose or board circuit damage;

Balance abnormal:full auto balance potentiometer misadjustment;

No reference signal:backplane power supply fault or poor contact;

Spindle zero offset:zero set potentiometer drift.

Product Brief

RELIANCE 0-48652 is MAXPAK+ spindle calibration meter board.

It is used for spindle speed calibration and feedback signal adjustment of Reliance MAXPAK+ spindle drive,widely used as spare part for machine tool spindle drive maintenance.

Disclaimer

All parameters are for reference only and not the basis of quotation. Goods are scarce,overseas delivery lead time 3-7 working days. It is only used for equipment maintenance and retrofit.
