RELIANCE 0-057427 Digital Input Module

Technical Specifications

Model:0-057427

Brand:RELIANCE

Product type:Digital Input Module

Weight:0.85kg

Dimension:220mm120mm25mm

Operating temperature:0℃ ~ 60℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:5%~85%,non-condensing

Certification:CE

System compatibility

0-057427 belongs to RELIANCE drive rack series digital input module.

Installed into Reliance control rack,works with CPU processor module,power supply board and output modules.

It is the field digital signal acquisition unit for the drive control system.

Commonly used for old industrial drive equipment maintenance and spare replacement.

Function

0-057427 is dedicated digital input module for RELIANCE drive rack system.

Collect on-site switch quantity digital signal and transmit to rack CPU module.

Complete signal isolation and filtering to suppress field interference noise.

Detect input channel status and upload signal state to control system in real time.

Overvoltage protection for each input channel to prevent surge damage.

Channel status indicator to show signal on/off condition.

Installation

Power off the whole control rack and cut main power supply.

Insert 0-057427 module into designated rack slot and lock the retaining latch.

Connect backplane bus and field digital signal wiring.

Separate low voltage signal wiring from high power circuit cable.

Power on system,verify each input channel signal collection.

Check channel indicator response with field switch signal.

Interface

Backplane bus connector,field digital signal terminal block,channel status LED indicators.

Feature

RELIANCE 0-057427,rack mounted digital input module.

Optical isolation design between field side and backplane bus.

Built-in surge suppression circuit for harsh industrial environment.

Individual LED indicator for every input channel.

Discontinued obsolete module,supply only for old automation drive system spare replacement.

Suitable for metallurgy,paper-making production line drive system renovation.

Diagnostic

All channels no signal:backplane power failure or module poor contact;

Single channel no input:field cable break or channel circuit damage;

Random signal jitter:signal wiring interference or grounding problem;

Indicator always off:input loop power missing;

Module unrecognized by CPU:backplane bus connector loose.

Product Brief

RELIANCE 0-057427 is rack digital input module.

It collects field digital switch signals for Reliance drive rack system,widely used as spare part for heavy industry drive system maintenance.

Disclaimer

All parameters are for reference only and not the basis of quotation. Goods are scarce,overseas delivery lead time 3-7 working days. It is only used for equipment maintenance and retrofit.
