MOOG D122-034-017C Servo Valve Amplifier Module

Technical Specifications

Model:D122-034-017C

Brand:MOOG

Product type:Servo Valve Amplifier Module

Supply voltage:±15V DC

Output signal:±40mA

Weight:0.75kg

Operating temperature:-20℃ ~ +70℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:10~90%

Certification:CE

System compatibility

D122-034-017C belongs to MOOG D122 series servo amplifier module.It is widely matched with hydraulic servo valves for material fatigue test bench,material testing machine and precision hydraulic closed-loop control system.It is complete replacement spare part for hydraulic equipment overhaul.

Function

D122-034-017C converts control command signal into driving current for servo valve.It features high signal stability and low drift.It provides accurate current output to realize closed-loop regulation of force,pressure and position for industrial hydraulic equipment.

Installation

Mount module on standard electrical cabinet rail.Connect power supply and signal wiring correctly.Check wiring before power on.Take anti-static protection during handling.

Interface

‑Power supply terminals

‑Signal input and output terminals

‑Module status indicator

Feature

MOOG D122 series servo amplifier module,low temperature drift,strong anti-interference,stable output.Typical faults:signal drift,no output,internal circuit damage.Inspect wiring and module status regularly.

Diagnostic

Fault phenomenon:no output signal,unstable output,signal deviation.Check power supply,wiring connection and internal circuit of the amplifier module.

Product Brief

D122-034-017C is MOOG D122 series servo valve amplifier module.It is a compact high stability drive component used to drive hydraulic servo valves for industrial closed-loop servo system overhaul and replacement.
