MOOG AWXX-009-D01 Servo Valve Speed Sensor

Technical Specifications

Model:AWXX-009-D01

Brand:MOOG

Product type:Magnetic Speed Pickup Sensor

Structure:Passive magnetic induction coil,non-contact detection

Output:Sine wave pulse signal

Gap range:0.3~0.8mm

Dimension:45mm*10mm

Weight:0.05kg

Operating temperature:-20℃ ~ +120℃

Storage temperature:-40℃ ~ +130℃

Relative humidity:10~90% non-condensing

Certification:CE

System compatibility

AWXX-009-D01 is MOOG dedicated magnetic speed sensor.It matches MOOG D920 series servo valves,widely used in hydraulic test bench,turbine control and high-precision hydraulic servo system.It is replacement spare part for servo valve overhaul.

Function

AWXX-009-D01 is passive magnetic speed pickup.It detects gear rotational movement and converts rotation speed into pulse signal,sends speed feedback signal to control unit for closed-loop rotational speed regulation of servo valve.

Installation

Mount sensor near rotating gear tooth,adjust sensing gap within specified range.Fix sensor securely and connect shielded signal wire.Perform signal test after assembly.Take anti-static protection during handling.

Interface

‑Two-core shielded signal wiring terminal

‑Sensor laser marking label

Feature

MOOG passive magnetic speed pickup,no external power supply.Typical faults:coil open circuit,cable fracture,sensing gap drift.Inspect pulse signal during overhaul.

Diagnostic

Fault phenomenon:no speed feedback,speed signal loss,signal jitter.Check coil continuity,sensor gap and cable integrity.

Product Brief

AWXX-009-D01 is MOOG non-contact magnetic speed pickup sensor,suitable for D920 series servo valve rotational speed feedback.It is critical feedback spare part for hydraulic servo equipment maintenance and replacement.
