MOOG A58179-001 Servo Valve Control Electronic Module

Technical Specifications

Model:A58179-001

Brand:MOOG

Product type:Servo Valve Control Electronic Module

Power supply:24V DC

Input signal:±10V analog command signal

Function:Analog signal conditioning,spool position closed-loop amplification,drive torque motor of servo valve

Dimension:145mm90mm28mm

Weight:0.75kg

Operating temperature:-20℃ ~ +70℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:10~90% non-condensing

Certification:CE

System compatibility

A58179-001 belongs to MOOG servo valve dedicated drive electronics.It matches MOOG series electro-hydraulic servo valves,widely used in material test bench,vibration simulation and precision hydraulic control system.It is spare part for legacy hydraulic equipment overhaul.

Function

A58179-001 is dedicated electronic drive module for servo valve.It receives external analog command signal,compares with valve spool position feedback signal,amplifies the error signal to drive torque motor,realizes high precision closed-loop control of servo valve spool.

Installation

Install module inside valve manifold or electrical cabinet,tighten mounting screws.Connect 24V DC power,command signal cable and servo valve feedback & coil wiring.Complete wiring inspection and calibration before commissioning.Take anti-static protection during handling.

Interface

‑DC power terminal

‑Analog command input terminal

‑Spool feedback and torque motor output terminal

‑Module identification label

Feature

MOOG compact servo valve drive electronic module.Typical faults:signal circuit damage,feedback channel failure,power circuit burnout.Inspect 24V power and signal wiring before replacement.

Diagnostic

Fault phenomenon:valve no response,zero drift,output unstable.Check DC power,command signal,feedback wiring and internal circuit status.

Product Brief

A58179-001 is MOOG servo valve control electronic module,used for signal processing and torque motor driving of electro-hydraulic servo valve,suitable for industrial hydraulic servo system maintenance and replacement.Anti-static protection must be followed during handling.
