MOOG 400317100LG High Speed CPU Machinery Protection Module

Technical Specifications

Model:400317100LG

Brand:MOOG

Product type:High Speed Central Processor Machinery Protection Module

Processor:High-speed dedicated CPU for machinery protection

Power supply:24V DC

Communication interface:Digital bus

Function:Real-time signal acquisition,condition monitoring,over-speed and mechanical fault protection,alarm & trip output

Dimension:245mm160mm35mm

Weight:1.4kg

Operating temperature:-20℃ ~ +70℃

Storage temperature:-40℃ ~ +85℃

Relative humidity:10~90% non-condensing

Certification:CE

System compatibility

400317100LG belongs to MOOG machinery protection shturl.cc is widely used in steam turbine,generator and rotating machinery monitoring system,realizes equipment safety interlock protection.It is spare part for legacy power plant control equipment overhaul.

Function

400317100LG is high-speed central processor module for mechanical protection.It collects rotating equipment vibration,speed and displacement signals in real time,judges abnormal working condition,trigger alarm or trip signal to protect rotating machinery from damage.

Installation

Install module in standard rack chassis,secure the mounting screws.Connect 24V DC power and signal bus wiring.Finish parameter configuration and function test before commissioning,check wiring tightness.Take anti-static protection during handling.

Interface

‑DC power terminal

‑Digital signal bus port

‑Signal input & relay trip output terminal

‑Module identification label

Feature

MOOG high reliable machinery protection CPU module.Typical faults:power supply failure,communication interruption,signal acquisition anomaly,internal chip aging.Inspect power voltage and bus communication status before replacement.

Diagnostic

Fault phenomenon:no module power-up,offline communication,false alarm or no trip action.Check DC power supply,bus cable,terminal connection and module firmware status.

Product Brief

400317100LG is MOOG high-speed CPU machinery protection module,for rotating machinery real-time monitoring and safety protection,applied to power plant equipment renovation and maintenance.Mainly used for replacement of industrial machinery protection control components.Anti-static protection must be followed during handling.
