Kollmorgen SR06200-Y024 Servo Motor Spare Part

Technical Specifications

Model:SR06200-Y024

Brand:Kollmorgen

Part No:SR06200-Y024

Product type:Permanent magnet brushless servo motor

Rated power:0.62kW

Rated speed:3000rpm

Continuous torque:2.0Nm

Rated voltage:200V AC

Protection class:IP64

Dimension:160mm90mm100mm

Weight:4.1kg

Feedback interface:Incremental encoder

Mounting:NEMA flange mounting

Operating temperature:0~40℃

Storage temperature:-20~70℃

Relative humidity:5~95% non-condensing

Certification:CE

System compatibility

SR06200-Y024 belongs to Kollmorgen Silverline servo motor family,matched with Kollmorgen BJRL,SR series rack servo amplifiers,widely used in old CNC equipment,medium precision positioning machinery,packaging and printing equipment.This is discontinued industrial spare part for equipment overhaul and maintenance.

Function

SR06200-Y024 is medium frame Silverline brushless servo motor with rare earth permanent magnet rotor.It features low cogging torque and smooth running performance.Incremental encoder provides high resolution position and speed feedback for closed-loop motion control.Suitable for medium load,continuous cycle operation,the suffix Y024 represents built-in 24V DC holding brake configuration.

Installation

Install SR06200-Y024 via standard NEMA flange mounting.Connect motor power cable,encoder feedback cable and brake power cable.Fasten coupling and mechanical connection,complete shielding and grounding inspection before power-on test.

Interface

‑3 phase motor power connector

‑Incremental encoder feedback connector

‑24V DC brake terminal

‑Shield grounding terminal

Feature

SR06200-Y024 is obsolete Kollmorgen spare part.Typical faults:winding insulation degradation,encoder damage,bearing wear,brake failure,shaft seal leakage,connector corrosion.Test winding resistance,insulation resistance and encoder pulse signal before replacement.

Diagnostic

Motor faults will trigger overload,overcurrent or position tracking alarm;motor no rotation,abnormal noise,axis jitter,brake release failure,positioning deviation.

Built‑in function:Convert electrical command into precise mechanical torque,realize high accuracy speed and position closed-loop control,as Kollmorgen Silverline series servo motor spare replacement.

Product Brief

SR06200-Y024 is Kollmorgen Silverline 0.62kW brushless servo motor,200V rated voltage,with 24V holding brake and encoder feedback,matched with BJRL series rack drives for legacy medium-duty automation equipment repair.Confirm feedback type and brake function before ordering.ESD protection required during handling and installation.
