Giddings & Lewis M.1300.6357 Analog Output Module

Technical Specifications

Model： M.1300.6357

Brand： Giddings & Lewis

Product Type: Rack mount multi-channel analog output PCB assembly for PiC900 CNC system

Module Feature:

Function: Analog output module for G&L PiC900 CNC platform. Converts digital motion commands from the CNC main controller into ±10V analog voltage signals, transmits analog setpoint signals to analog servo amplifiers to control spindle speed and feed axis velocity for heavy horizontal boring mills and large machining centers.

Signal range: ±10V analog output

Bus interface: PiC900 parallel backplane bus for digital data exchange

Onboard components: High precision D/A converters, signal buffer circuits, noise filtering and short-circuit protection

LED indicators: POWER, ACT, FAULT diagnostic lights

Hardware self-diagnosis: D/A channel integrity test, output overrange detection, backplane communication verification

Programming software: PiCPro for channel scaling, offset calibration and module diagnostic test

Electrical Parameters

Backplane supply: +5VDC Analog reference supply: ±15VDC

Power consumption: Max 8.2W

Mechanical & Structure:

Mounting: PiC900 rack slot mount with gold finger edge connector

Weight: 0.98kg

Protection class: IP20

Environmental:

Operating temperature: 0℃ ~ +55℃

Ambient humidity: 5~85% non-condensing

Certification: CE

Status: Manufacturer discontinued legacy PiC900 analog output module

System compatibility

Compatibility description: M.1300.6357 belongs to Giddings & Lewis PiC900 analog I/O family. Compatible with PiC900 CPU, motion control boards and Centurion series analog servo amplifiers. Widely fitted on heavy G&L horizontal boring mills.

Function

Function description: M.1300.6357 is multi-channel analog output board manufactured by Giddings & Lewis. It performs digital-to-analog conversion for PiC900 CNC system. It receives digital command data from the rack backplane and outputs stable ±10V analog voltage to servo drives and spindle control unit to regulate motor speed. Onboard filtering suppresses industrial interference for smooth analog signal output. It is legacy analog command spare for heavy G&L CNC boring mills.

Installation

Installation steps: Follow lockout/tagout safety procedure before installation. Cut off rack +5V and ±15VDC analog power. Insert M.1300.6357 board into PiC900 rack slot and secure gold finger connector. Connect shielded analog signal cables to output terminal block. Calibrate channel offset and gain via PiCPro. Power on rack, verify ACT LED status and check analog output signal accuracy.

Interface

Interface list: PiC900 backplane gold finger connector, multi-channel analog output screw terminal block,on-board POWER / ACT / FAULT LED indicators for Giddings & Lewis M.1300.6357.

Diagnostic

Troubleshooting: No analog output: Check ±15V reference power, terminal wiring or D/A channel damage. FAULT LED lit: Output short circuit, backplane communication failure or reference voltage anomaly. Signal drift: Temperature drift, poor grounding or aged analog component.

Product Brief

Brief description: M.1300.6357 is Giddings & Lewis legacy PiC900 analog output module,with ±10V D/A conversion to send speed command signals to servo and spindle drives on heavy CNC boring mills,discontinued CNC analog output PCB spare.
