Giddings & Lewis 501-101400 Rack Power Supply Module

Technical Specifications

Model： 501-101400

Brand： Giddings & Lewis

Product Type: Plug-in rack mount power supply module for legacy NumeriPath CNC control rack

Module Feature:

Function: Rack power supply module for Giddings & Lewis NumeriPath CNC platform. Converts AC mains input to multiple regulated DC voltages, supplies power to CPU, servo interface, I/O and analog circuit boards inside CNC rack for heavy horizontal boring mills and large machining centers.

Input: AC mains input

DC Output: +5VDC digital logic power, ±15VDC analog reference power

Built-in protection: Overcurrent, overvoltage, overtemperature and short-circuit protection circuits

LED indicators: POWER, FAULT diagnostic lights

Hardware self-diagnosis: Output voltage monitoring, overload detection, internal temperature monitoring

Programming software: Giddings & Lewis proprietary CNC software for power status monitoring and fault diagnosis

Electrical Parameters

Rated AC Input: 115/230V AC selectable

Max power rating: 160W

Mechanical & Structure:

Mounting: CNC control rack plug-in module

Weight: 2.2kg

Protection class: IP20

Environmental:

Operating temperature: 0℃ ~ +55℃

Ambient humidity: 5~85% non-condensing

Certification: CE

Status: Manufacturer discontinued legacy CNC rack power supply module

System compatibility

Compatibility description: 501-101400 belongs to Giddings & Lewis NumeriPath power family. Compatible with matching rack backplane, executive CPU, analog servo and digital I/O boards. Widely fitted on vintage heavy G&L horizontal boring mills.

Function

Function description: 501-101400 is rack power supply module manufactured by Giddings & Lewis. It provides stable multi-channel DC power for all plug-in boards within NumeriPath CNC rack. +5V supplies digital logic chips, ±15V provides reference voltage for analog servo and analog I/O boards. Integrated protection circuits can cut off output to prevent backplane and board damage under overload, short-circuit or over-temperature conditions. It is legacy power spare for old heavy G&L CNC boring mills.

Installation

Installation steps: Follow lockout/tagout safety procedure before installation. Disconnect AC mains power to control cabinet. Insert 501-101400 module into rack slot and secure retainer. Connect AC input wiring. Restore AC power, check POWER indicator, verify each DC output voltage and test all rack boards.

Interface

Interface list: AC input terminal block, rack backplane gold finger connector,on-board POWER / FAULT LED indicators for Giddings & Lewis 501-101400.

Diagnostic

Troubleshooting: No power output:Check AC input, internal fuse failure or power circuit damage. FAULT LED lit:Overload, DC bus overvoltage/undervoltage or internal overheat. Unstable DC voltage:Aging electrolytic capacitor or poor backplane contact.

Product Brief

Brief description: 501-101400 is Giddings & Lewis legacy rack power supply module,supplies +5VDC and ±15VDC regulated power to NumeriPath CNC rack boards on heavy CNC boring mills,discontinued CNC power spare module.
