Fives Group 502-03518-03 Axis Control Processor Module

Technical Specifications

Model： 502-03518-03

Brand： Fives Group

Product Type: Rack mount axis control processor PCB assembly for legacy CNC system

Module Feature:

Function: Axis control processor module for Fives Group CNC platform. Receives motion trajectory commands from main CPU, performs multi-axis interpolation, closed-loop position and velocity regulation, outputs control instructions to servo interface board for heavy horizontal boring mills and large machining centers.

Bus interface: Parallel backplane bus for high-speed bidirectional data exchange with CNC main CPU and encoder feedback boards

Onboard components: Motion calculation IC, position counter, timing oscillator, watchdog circuit, address decoding and bus interface logic

LED indicators: POWER, RUN, AXIS, FAULT diagnostic lights

Hardware self-diagnosis: Power-on self-test, watchdog supervision, backplane bus integrity check, position loop diagnostic test

Programming software: Fives Group proprietary CNC software for axis parameter configuration, servo gain tuning and board diagnostic testing

Electrical Parameters

Backplane supply: +5VDC

Power consumption: Max 9.4W

Mechanical & Structure:

Mounting: Rack slot mount with gold finger edge connector

Weight: 1.03kg

Protection class: IP20

Environmental:

Operating temperature: 0℃ ~ +55℃

Ambient humidity: 5~85% non-condensing

Certification: CE

Status: Manufacturer discontinued legacy CNC axis control processor module

System compatibility

Compatibility description: 502-03518-03 belongs to Fives Group CNC motion control board family. Compatible with Fives Group main CPU, servo interface boards and encoder feedback modules. Widely deployed on heavy Fives Group horizontal boring mills.

Function

Function description: 502-03518-03 is dedicated axis motion control board manufactured by Fives Group. It undertakes real-time multi-axis interpolation and closed-loop position control, offloading motion computation from the main CPU. It compares target position with encoder feedback continuously and generates velocity commands for servo control, ensuring high-precision contour machining. The onboard watchdog circuit monitors runtime status and triggers alarm when abnormality occurs. It is legacy axis motion control spare for heavy CNC boring mills.

Installation

Installation steps: Follow lockout/tagout safety procedure before installation. Cut off rack +5V backplane power. Insert 502-03518-03 board into rack slot and secure gold finger connector. Power on rack, verify RUN and AXIS LED indicators, load axis parameters, perform servo tuning, test single-axis jog and multi-axis contour machining function.

Interface

Interface list: Backplane gold finger connector,on-board POWER / RUN / AXIS / FAULT LED indicators for Fives Group 502-03518-03.

Diagnostic

Troubleshooting: Axis jogging invalid: Check backplane contact condition, axis parameter setting or bus communication fault. FAULT LED lit: Watchdog timeout, position calculation error or backplane communication failure. Contour machining deviation: Improper servo tuning, aging timing component or encoder signal interference.

Product Brief

Brief description: 502-03518-03 is Fives Group legacy CNC axis control processor board,for multi-axis interpolation and closed-loop position control for heavy CNC boring mills,discontinued CNC motion control PCB spare.
