DMC-001M Motion Control Card

Feature & Principle

It is an industrial multi-axis motion control card. It receives positioning commands from host computer or PLC, outputs pulse and direction signals to servo drives or stepper drivers to realize accurate position control. It integrates trapezoidal and S-curve acceleration/deceleration algorithm, supports point-to-point positioning, continuous interpolation, electronic gear and homing function. It has built-in limit and emergency stop signal detection to improve operation safety. Widely used in dispensing machines, packaging equipment, cutting and handling automation machines.

Specifications

Model: DMC-001M Type: Motion control card Output: Pulse + direction Control mode: Positioning, interpolation, electronic gear Signal: Forward / reverse limit, home, alarm input Power supply: 24 VDC Mounting: DIN rail or internal board installation Application: Dispensing machine, cutting machine, packaging automation, handling equipment Certification: CE

Components & Diagnostics

Main control chip, pulse output circuit, optocoupler isolation circuit, terminal block, status LED indicator. Common faults: pulse loss, positioning deviation, limit signal failure, communication interruption.

Product Brief

DMC-001M motion control card, industrial positioning control spare widely used for automation equipment overhaul and replacement.
