Atlas Copco TC52SM Tightening Controller

Technical SpecificationsModel:TC52SM Brand:Atlas Copco Product Type:TC5000 Series Servo Tightening Controller with Safety Module Power Supply:200-480V AC,50/60Hz,400W Mounting:Cabinet DIN rail mount Operating temperature:0℃ ~ +45℃ Storage temperature:-20℃ ~ +70℃ Relative humidity:5%~95%, non-condensing Weight:5.2kg Dimension:220mm130mm280mm Protection:IP20

System compatibilityTC52SM belongs to Atlas Copco TC5000 series single spindle servo tightening controller. Compatible with Atlas Copco servo nutrunner spindles for fixed assembly stations. It is equipped with integrated safety module and standard serial communication interface, supporting connection to PLC and HMI devices. This controller uploads tightening results and full traceability data to PLC and MES system, suitable for high-precision single spindle bolt tightening on automotive assembly lines as industrial spare part.

FunctionTC52SM is high precision servo torque controller for single spindle assembly station with enhanced safety functions. This Atlas Copco TC5000 controller supports multi-step tightening sequences, real-time torque-angle curve monitoring and OK/NOK tightening judgement. It stores tightening history records and supports parameter backup, built-in enhanced emergency stop safety relay and safety interlock logic, widely used for single spindle bolt assembly at automotive and heavy machinery assembly stations, serving as reliable industrial spare part.

InstallationCut off power before installation. Mount the TC52SM Atlas Copco controller on DIN rail inside electrical cabinet. Connect AC power, servo spindle motor cable and serial communication cable. Configure tightening programs via ToolsTalk software. Complete spindle calibration and test tightening before online operation of this TC5000 controller.

InterfaceServo spindle drive port, digital I/O terminals, serial communication port, Ethernet service port, safety interlock terminal block, front operation panel, status LED indicators, E-stop safety relay terminal for TC52SM Atlas Copco tightening controller.

FeatureAtlas Copco TC5000 single spindle servo controller, integrated safety module, serial communication interface, service Ethernet port, real-time torque-angle monitoring, safety interlock function, built-in E-stop safety relay, tightening data storage, IP20 cabinet protection. This discontinued legacy industrial spare part is used for single spindle bolt tightening system maintenance and replacement.

DiagnosticController no power: check AC input, fuse and wiring for TC52SM. Spindle no rotation: check spindle cable, motor winding and enable signal. Tightening result deviation: verify spindle calibration, tightening program and mechanical condition of this controller. Serial communication abnormal: check serial cable, station address, PLC configuration. Safety interlock fault: verify safety circuit wiring, safety relay and E-stop loop continuity. Front panel display fault: check internal display connector and controller firmware.

Product BriefTC52SM is Atlas Copco TC5000 series single spindle servo tightening controller. This controller widely used in automotive and machinery assembly production lines for high precision single spindle tightening, built-in safety module and serial interface for factory device communication, popular industrial spare part for fixture assembly system.
